Dewetron

ABOUT DEWETRON

DEWETRON is the premium manufacturer of highly intuitive, end-to-end test & measurement systems designed to make the world more predictable, efficient, and safe. DEWETRON systems are modular in design allowing us to deliver reliable measurement data and provide flexible, needs-based data acquisition capability for aerospace & defense, the automotive industry, the power & energy sector as well as the industrial & manufacturing companies.

Vision

Thanks to more than 30 years of experience and innovation, DEWETRON has earned the trust of the global measurement market. Well-known companies worldwide use more than 25,000 DEWETRON systems and over 400,000 measuring channels on a continuous basis. This way, a start-up has become an established and internationally recognized company. Today, we count more than 120 employees in over 25 countries. In addition to several locations worldwide, we have access to a very well-maintained partner network. This allows us to support our customers at any time and any place.

Certified Quality

In addition to our strong commitment to total quality management, the development and production of our equipment meet the high requirements of various standards such as ISO9001, ISO14001, and ISO17025. These certifications guarantee compliance with rigorous quality procedures and documentation of every aspect of our business. Moreover, our systems meet a wide range of specifications and norms (EMI, CE, etc).



1.  Power Analyzer

2.  Data Acquisition Systems

3.  Signal Conditioning

4.  OXYGEN Software

5.  Components and Sensors

6.  Downloads

Power Analyzer

Build the Power Analyzer you need with our dedicated power modules. No matter if you need a small, portable Power Analyzer or one for 19” built-in or test stand, here you will find the perfect high-precision Power Analyzer for every field of application.


We offer a unique combination of flexible hardware with high-end software for high-precision power measurement, analysis and reporting. Measure high-voltage and current in perfect synchronization with further analog inputs such as temperature, vibration or noise as well as other data sources like CAN, SCPI or FlexRay. Use the DEWETRON Mixed Signal Power Analyzer.

The Smallest

The Smallest

The Smallest

Dewetron offers you a unique modularity: 4 slots on each power module or even 8 slots of the TRION3-1810-SUB-8 can be equipped with different

sub-modules. Choose between direct current measurement modules or voltage modules to connect almost any kind of current or voltage transducer.

Create your individual input configurations with our sub-modules. They are user-exchangeable at any time and automatically detected. The calibration data is directly stored inside the sub-module.


Return to Top

PA-TRIONet3

The Portable

The Smallest

The Smallest

Precise voltage and current front end combined with high sampling rates are base for power analysis applications. Dewesoft power analyzer will not only provide all that, but it will also give you the flexibility to measure other parameters like RPM, vibration, temperature, strain, stress, GPS, CAN and more, all fully synchronized. This gives you a great advantage compared to conventional power analyzers. You can finally have one system that covers all your measurement and analysis needs.




DEWE3-A4

The stationary

The stationary

The stationary

Dewetron offers you a unique modularity: 4 slots on each power module or even 8 slots of the TRION3-1810-SUB-8 can be equipped with different

sub-modules. Choose between direct current measurement modules or voltage modules to connect almost any kind of current or voltage transducer.

Create your individual input configurations with our sub-modules. They are user-exchangeable at any time and automatically detected. The calibration data is directly stored inside the sub-module.


 Return to Top

DEWE3-PA8-RM

The All-In-One

The stationary

The stationary

Dewesoft products offer support for various aerospace interfaces like PCM telemetry, ARINC 429, MIL-STD-1553, IRIG-106 CHAPTER 10, iNET, as well as Ethernet protocols with the syncronised acquisition of all the mentioned interfaces. This offers a unique solution for a wide variety of aerospace and defense applications. Whether you operate a ground station or you are testing or monitoring a flight, rocket, satellite, or military vehicle, Dewesoft offers a unique all-in-one solution for aerospace and defense testing and monitoring applications.



DEWE3-PA8

DAQ Systems

ALL-IN-ONE SYSTEMs

ALL-IN-ONE SYSTEMs

ALL-IN-ONE SYSTEMs

All-in-One systems with built-in display are the most convenient data acquisition hardware systems for mobile applications.  These systems are equipped with a powerful PC inside and are easily configured.


Return to Top

See all our All in Ones

MAINFRAMES

ALL-IN-ONE SYSTEMs

ALL-IN-ONE SYSTEMs

Mainframes are very popular for test benches and environments that are poorly accessible or hazardous to people. To that end, the compact and flexible DAQ hardware mainframes are used with external displays.



See our Mainframes

FRONT-ENDS

ALL-IN-ONE SYSTEMs

FRONT-ENDS

Front-end data acquisition hardware is high-speed channel expansion for other DEWETRON DAQ systems. Connect them via USB or Ethernet.




See our Front-Ends

DAQ All in One Systems

Dewe3-A4


The DEWE3-A4 DAQ system is the best solution for portable all-in-one data acquisition. The four TRION(3) slots for up to 32 analog measurement inputs and the 1 TB data SSD, in combination with the intuitive OXYGEN measurement software, make it universally and flexibly applicable. Whether field measurements, in the vehicle, or on the test bench – the measurement possibilities with this compact and rugged system are limitless.


  • Up to 32 analog inputs (via exchangeable TRION(3) modules)
  • Digital inputs, counter and CAN integrated
  • Up to 10 MS/s simultaneous sampling rate
  • Comprehensive SYNC options
  • Isolated DC power supply & optional battery pack


Return to Top

Find out more

Dewe3-A4L

The portable DEWE3-A4L is a cost-efficient data acquisition system for continuous high-speed recording applications. The powerful DAQ system with the built-in data logger offers up to 32 analog measurement inputs and is ready to use immediately. User-friendliness is guaranteed due to the multi-touch display and the multi-touch-base OXYGEN software. Choose between Windows or Linux operating system.

Benefit from the modular platform, and configure the DEWE3-A4L individually according to your measurement tasks using TRION(3) modules for different signal inputs up to 10 MS/sec.


  • Up to 32 analog inputs (via exchangeable TRION(3) modules)
  • Up to 10 MS/s simultaneous sampling rate



Find out more

dewe2-a13

dewe2-a13


DEWE2-A13 WITH UP TO 104 INPUT CHANNELS FOR UNIVERSAL MEASUREMENTS

High channel count data acquisition (DAQ) in a compact, all inclusive system – 17″ display, keyboard and internal PC. ONE System – multiple signals
















Find out more

Mainframe Systems

DEWE3-M4

With its high flexibility and ruggedness and the internal buffer battery that bridges power outages for up to 10 minutes, the DEWE3-M4 is predestined for in-vehicle testing.


  • Up to 32 analog inputs (via exchangeable TRION(3) modules)
  • Isolated DC power supply
  • Optional internal UPS buffer battery
  • Stackable battery pack available










Return to Top

Find out more

DEWE3-M8s

The portable DEWE3-M8s is DC and battery powered and therefore perfect for automotive applications like in-vehicle power and efficiency measurements, durability or vehicle dynamics tests, WLTP or e-charger measurements, and many more.

  • Up to 64 analog inputs (via 8 exchangeable TRION(3) modules)
  • Several powering options
  • 2 integrated battery bays for uninterruptible power supply (UPS)










Find out more

DEWE3-RM4

You need a rack-mountable DAQ system? Then you are right with our rack-mount Mainframes. Profit from the easy integration with 19” mounting kit, fan slot at the front for easy maintaining and the silent cooling. The Mainframe DAQ systems are fully modular via user-exchangeable TRION(3) modules for analog, digital, CAN inputs, counter, etc. The resolution is selectable up to 24-bit and they can be upgraded with standard PC components.


  • Rack-mount or benchtop data acquisition mainframe
  • Silent cooling, easy-to-maintain fan slot
  • Gapless storage of raw data up to 1 GB/s
  • 19” mounting kit available

Find out more

DEWE3-RM8


You need a rack-mountable DAQ system? Then you are right with our rack-mount Mainframes. Profit from the easy integration with 19” mounting kit, fan slot at the front for easy maintaining and the silent cooling. The Mainframe DAQ systems are fully modular via user-exchangeable TRION(3) modules for analog, digital, CAN inputs, counter, etc. The resolution is selectable up to 24-bit and they can be upgraded with standard PC components.


  • Rack-mount or benchtop data acquisition mainframe
  • Silent cooling, easy-to-maintain fan slot
  • Gapless storage of raw data up to 1 GB/s
  • 19” mounting kit available


Return to Top

Find out more

DEWE3-RM12

DEWE3-RM12

You need a rack-mountable DAQ system? Then you are right with our rack-mount Mainframes. Profit from the easy integration with 19” mounting kit, fan slot at the front for easy maintaining and the silent cooling. The Mainframe DAQ systems are fully modular via user-exchangeable TRION(3) modules for analog, digital, CAN inputs, counter, etc. The resolution is selectable up to 24-bit and they can be upgraded with standard PC components.


  • Rack-mount or benchtop data acquisition mainframe
  • Silent cooling, easy-to-maintain fan slot
  • Gapless storage of raw data up to 1 GB/s
  • 19” mounting kit available



Find out more

DEWE3-RM16

DEWE3-RM12

You need a rack-mountable DAQ system? Then you are right with our rack-mount Mainframes. Profit from the easy integration with 19” mounting kit, fan slot at the front for easy maintaining and the silent cooling. The Mainframe DAQ systems are fully modular via user-exchangeable TRION(3) modules for analog, digital, CAN inputs, counter, etc. The resolution is selectable up to 24-bit and they can be upgraded with standard PC components.


  • Rack-mount or benchtop data acquisition mainframe
  • Silent cooling, easy-to-maintain fan slot
  • Gapless storage of raw data up to 1 GB/s
  • 19” mounting kit available



Find out more

DEWE3-PA8-RM

DEWE3-PA8-RM

DEWE3-PA8-RM

 Build the Power Analyzer you need with our dedicated power modules. No matter if you need a small, portable Power Analyzer or one for 19” built-in or test stand, here you will find the perfect high-precision Power Analyzer for every field of application.

We offer a unique combination of flexible hardware with high-end software for high-precision power measurement, analysis and reporting. Measure high-voltage and current in perfect synchronization with further analog inputs such as temperature, vibration or noise as well as other data sources like CAN, SCPI or FlexRay.


Return to Top

See More

SIGNAL CONDITIONING

ALL TRION3 & TRION MODULES

The user exchangeable, multichannel  TRION3  and TRION modules provide analog-digital conversion on each channel.



Return to Top

Find out more

TRION(3) POWER MODULES

Highspeed power modules of the  TRION3  and TRION modules series for 4-phase power analysis. Highest flexibility with user exchangeable modules and additional sub-modules.


Find out more

MULTIFUNCTIONAL TRION(3) MODULES

MULTIFUNCTIONAL TRION(3) MODULES

Full flexibility and high channel density with our TRION-MULTI universal analog amplifiers. Direct connection of: Bridge, voltage, current, IEPE, resistance, potentiometer, RTD, counter and CAN as well as charge, temperature and LVDT via MSI adapter.

Find out more

MSI SENSOR ADAPTER

RUGGED LOW-SPEED CHANNEL EXPANSION (XR)

MULTIFUNCTIONAL TRION(3) MODULES



Modular Smart Interfaces (MSIs) are add-ons for our TRION(3)-18xx-MULTI modules and the TRION-x-dLV-CB16-D9 sensor connection box with TRION-1xxx-dlV-32 to expand their measurement functionality.


MSI adapters in combination with TRION(3)-18xx-MULTI modules extend the measurement capability to charge, LVDT or thermocouple input.


MSIs in combination with TRION-1xxx-dLV-32 and TRION-x-dLV-CB16-D9 sensor connection box extend the measurement modes to bridge, IEPE®, charge, LVDT, thermocouple, Pt100 to Pt2000, and voltage up to 200V.


Return to Top

Find out more

RUGGED LOW-SPEED CHANNEL EXPANSION (XR)

RUGGED LOW-SPEED CHANNEL EXPANSION (XR)

RUGGED LOW-SPEED CHANNEL EXPANSION (XR)

Extend your measurement system with our low-speed channel expansions for temperature, voltage, current or resistance temperature measurements. The 8-channel modules combine analog signal conditioning and A/D convertion in an extremely rugged box. The interface is software programmable, so you are free to select between CAN or RS485 interface.


Used for precision data acquisition of slow signals in rough environments, e.g. in an engine bay of a vehicle, high-quality data logging of environmental conditions or expansion of dynamic DEWETRON instruments with up to 200 Hz sample rate per channel.




Find out more

SIGNAL CONDITIONING CHASSIS & AMPLIFIERS

RUGGED LOW-SPEED CHANNEL EXPANSION (XR)

RUGGED LOW-SPEED CHANNEL EXPANSION (XR)

 The isolated, single-channel DAQP-STG amplifier offers bandwidth up to 300 kHz and high isolation up to 1.8 kVRMS. The RS-485 interface supports the easy configuration. The DAQP-STG amplifier offers a conditioned signal output of ±5 V.

  • Channels: 1 isolated
  • Bandwidth: 300 kHz
  • Sensor Supply: 0-12 V, 0-20 mA
  • Voltage range: ±10 V
  • Voltage input: ±500 μV to ±10 V (up to ±200 V only with MSI-BR-V-200)
  • Bridge, strain gauge: ±0.1 to ±1000 mV/V (@ 5 VDC excitation)
  • Piezoresistive bridge: ±0.5 to ±10000 mV/mA (@ 1 mA excitation)
  • RTD: Resistance Temperature Detector (Pt100 to Pt2000), 9 resistance ranges (8 to 4000 Ω)
  • Resistance: 25 mΩ to 100 kΩ

Find out more

OXYGEN - DEWETRON'S INTUITIVE MEASUREMENT SOFTWARE

OXYGEN 7.0: Great usability and exciting new features, especially modal test. The new release is ava

 The OXYGEN measurement software is the most intuitive and easy-to-use software in the data acquisition sector. Its instruments and controls make it easy to navigate through tons of data.

Made by DEWETRON.

  • All-in-one software for measurement, visualization, and analysis
  • Wide range of interfaces for testbed integration – including
    remote control capability via TCP/IP
  • OXYGEN-SDK plugin interface for customization
  • Unlimited installations for data view and analysis (license-free)




Download the PDF here  Download OXYGEN Brochure

Download the PDF here  Download OXYGEN SDK Brochure

Software Installer Go to OXYGEN Software Installer Download

Online Help Go to OXYGEN ONLINE HELP


Return to Top

Find Tickets

DATA ACQUISITION

DATA ACQUISITION

DATA ACQUISITION

Data acquisition is one of the core features of OXYGEN. It is capable of continuous and synchronous acquisition of data from several sources: analog, digital, encoder, CAN, Ethernet, video, GPS and much more.

  • Analog data with up to 10 MS/s via TRION3
  • Digital and encoder data with automatic rpm and angle calculation
  • CAN(-FD) decoding via *.dbc, including  J1939. Compatible with Vector VN-series (option)
  • Ethernet receiver for external sensors (option)
  • Video data from USB or GigE-camera
  • Precision GPS position data via TRION, GeneSys ADMA or OxTS RT series
  • Plugin to request and decode OBD2 parameters (from OXYGEN 5.7)


Return to Top

MODAL TEST

DATA ACQUISITION

DATA ACQUISITION



With OXYGEN’s modal test option, you can analyze the frequency characteristics of a mechanical structure to determine resonances, damping characteristics and more.

  • DUT excitement via modal hammer
  • SISO & SIMO tests with moving hammer and moving sensor
  • Calculation of
    • Complex transfer function
    • Coherence of several hits
    • Mode indicator function
  • Various interactive visualization options
  • Data export into *.uff and other formats for post processing

COMPONENTS & SENSORS

POWER SUPPLY OPTIONS

CURRENT TRANSDUCERS & SENSORS

POWER SUPPLY OPTIONS

 DW2-UPS-250-DC

  • Battery charger and system power supply
  • 3 hot-swappable batteries
  • 11 to 32 VDC input voltage
  • Output voltage:
    • 24 VDC (connected to DC)
    • 12 to 16 VDC (running from batteries)




DEWE-POW-24-450

  • External system power supply
  • 100 to 240 VAC input voltage
  • 24 VDC output voltage
  • Max. 450 W


Return to Top

See More

CAMERAS

CURRENT TRANSDUCERS & SENSORS

POWER SUPPLY OPTIONS

DEWETRON offers several camera types from Alvium to complete your data acquisition system.  Then you are well prepared for your measurement task with perfectly synchronized video data. For example:


CAM-ALVIUM-G1-040

  • Small and lightweight industrial GigE camera with high image quality
  • Up to 276 fps at 728 x 544 px resolution (0.4 MP)
  • Synchronization via external trigger
  • Package includes:
    • Light ALVIUM camera
    • Cable set (5 m) for data transfer, power supply and trigger
    • Mounting plate and suction cup for easy mounting

See More

CURRENT TRANSDUCERS & SENSORS

CURRENT TRANSDUCERS & SENSORS

CURRENT TRANSDUCERS & SENSORS

DEWETRON offers several solutions for current measurement from simple shunts to current clamps and high-precision zero flux transducers. There are versions for pure AC current which do not need any power supply and versions for DC and AC current which can be supplied from the DEWETRON instrument. Have a look at the tables below.

You are looking for an RPM or angle sensor to complete your DAQ system for your demanding measurement task? Then have a look at our Tape Sensor by clicking the button below.






See More

Downloads

Files coming soon.

Copyright © 2024 GenTek Inc. - All Rights Reserve

GenTek Inc.

212 Pop Top Lane

Daytona Beach, FL  32124

gentek@gentekrep.com

813-961-0689

Powered by

Cookie Policy

This website uses cookies. By continuing to use this site, you accept our use of cookies.

DeclineAccept & Close
