Diversified Technical Systems, Inc.


ABOUT DTS

DTS specializes in miniature DAQ and portable data logger solutions for a variety of applications including product development, performance validation and safety testing. Engineered for extreme test environments, DTS compact data logger and sensors are rugged and reliable.

Mission

To be the most trusted provider of measurement solutions in every market we serve.

Vision

Deliver superior technology and create positive customer experiences through creativity, integrity, and hard work.

Values

-  Design innovative products that advance industry capability and add value to society.

-  Build meaningful relationships with customers.

-  Foster team spirit and personal growth.

-  Make decisions based on smart business practices.

-  Encourage a positive environment with a family spirit.

Diversified Technical Systems, Inc.

DAQ & SENSORS

Diversified Technical Systems, Inc. specializes in rugged, miniature data acquisition systems and sensors for critical testing. Based in Southern California, DTS technical centers and sales partners worldwide support critical testing in a variety of industries including automotive, aerospace, injury biomechanics, sports and military & defense.

DYNAMIC EXPERTISE

Manufacturing rugged test and measurement solutions for extreme environments is our expertise. Fortune 500 companies rely on DTS measurement solutions for crash testing a vehicle into a barrier at 50 mph, space capsule impact testing to ensure crew safety or testing an MRAP to advance soldier protection . . . it’s all in a day’s work for DTS equipment.

Award-Winning

Inc. Magazine named DTS three times as one of the nation’s fastest-growing private companies. DTS also received numerous “Best of Sensors Gold” and Small Business Innovation Research (SBIR) awards. BAE Systems Chairman’s Award recognized DTS’s work on the Headborne Energy Analysis and Diagnostic Systems (HEADS) smart helmet sensor and the U.S. Army named HEADS as one of “The Greatest Inventions of 2011.”

DTS Applications

CRASH SAFETY

Military and Defense

CRASH SAFETY

DTS is a leading manufacturer of crash safety solutions for occupant injury, pedestrian safety, and automotive crash test. DTS understands crash safety, ensures every customer gets the right DAS safety solution for their application, and offers expert technical support for automotive crash testing worldwide.


Return to Top

AUTOMOTIVE

Military and Defense

CRASH SAFETY

DTS automotive data acquisition systems are complete test and measurement solutions. Specializing in rugged onboard DAQ for automotive data collection, DTS systems are engineered to support crash safety, sled testing, off road, and NVH vibration data acquisition collection

Military and Defense

Military and Defense

Military and Defense

DTS offers military-hardened sensors and DAQ for injury assessment and military vehicle testing. DTS das military systems are ultra-small and designed to be onboard vehicles and embedded in helmets or other protective gear. DTS military sensors are ideal for auditory measurements for hearing protection/enhancement devices (HPEDs) and blast overpressure, which may result in mild traumatic brain injuries and skeletal injuries.

Aerospace

Sports and RECREATION

Military and Defense

DTS flight-ready data acquisition is optimized for low size, weight and power (SWaP). Each data recorder works standalone or can be networked for high channel tests. The SLICE6 AIR aerospace data recorder offers real-time streaming in IRIG Chapter 10 or TmNS, plus onboard data recording to flash memory


Return to Top

INJURY BIOMECHANICS

Sports and RECREATION

Sports and RECREATION

Top manufacturers, test labs and research universities worldwide use DTS data acquisition systems and sensors for injury biomechanics testing. From R&D to regulation requirements, and soldier safety to sports helmets, DTS DAQ and sensors provide reliable, repeatable data for critical injury biomechanics testing.

Sports and RECREATION

Sports and RECREATION

Sports and RECREATION

DTS DAQ and sensors are ideal for safety and performance testing sports equipment and helmets. The ultra-small, lightweight systems can be embedded on or in a crash dummy helmet without altering test dynamics. Manufacturers, researchers and test laboratories make DTS an integral part of their  measurement solutions for sports and helmet testing.

Idustrial

Idustrial

Idustrial

DTS flight-ready data acquisition is optimized for low size, weight and power (SWaP). Each data recorder works standalone or can be networked for high channel tests. The SLICE6 AIR aerospace data recorder offers real-time streaming in IRIG Chapter 10 or TmNS, plus onboard data recording to flash memory


Return to Top

DAQ Systems

Slice nano

Slice micro

Slice micro


Miniature, modular, rugged SLICE  NANO data acquisition systems are ideal for embedded test applications. SLICE NANO supports a variety of external sensors, includes full signal conditioning and writes data directly to flash memory.



Technical Specifications:  Click Here


Return to Top

Slice micro

Slice micro

Slice micro


Ultra-small, modular, rugged SLICE MICRO data acquisition systems are ideal for embedded test applications. SLICE MICRO supports a variety of external sensors, includes full signal conditioning and writes data directly to flash memory.



Technical Specifications:  Click Here

slice ip68

Slice micro

slice ip68


Waterproof, miniature, modular SLICE IP68 data acquisition systems are IP68 rated for water and dust ingress. SLICE IP68 supports a variety of external sensors, includes full signal conditioning and writes data directly to flash memory.



Technical Specifications:  Click Here



slice 6

SLICE6 AIR

slice ip68


The miniature, rugged SLICE6 data acquisition system is designed for test applications that require high-speed sampling with precision timing. An IEEE 1588 compliant Ethernet switch allows PTPv2 daisy-chaining of hundreds of channels.



Technical Specifications:  Click Here


Return to Top

SLICE6 AIR

SLICE6 AIR

SLICE6 AIR


Miniature SLICE6 AIR data acquisition units are ideal for rapid deployment modification and compatibility testing for aerospace and in-flight applications. Each standalone SLICE6 AIR features universal analog sensor support, flash memory and real-time streaming in IRIG (CH10 or TmNS).


Technical Specifications:  Click Here

SLICE PRO

SLICE6 AIR

SLICE6 AIR


Modular and rugged, the mega-sample SLICE PRO is a complete standalone data acquisition system.  SLICE PRO supports a variety of sensor inputs, plus airbag squib fire, trigger distribution, digital inputs and more.




 Technical Specifications:  Click Here

SLICE PRO LAB

SLICE PRO LAB

SLICE PRO LAB


SLICE PRO LAB is a complete laboratory version of the crashworthy SLICE PRO data acquisition system. SLICE PRO LAB supports a variety of sensor inputs and airbag squib fire, making it ideal for ATD dummy calibration and non-destructive testing.




Technical Specifications:  Click Here


Return to Top

TDAS G5

SLICE PRO LAB

SLICE PRO LAB


Compact and rugged, the TDAS G5 data acquisition system offers flexibility and reliability. TDAS G5 is the original in-dummy DAS for WorldSID (ISO 15830-4), plus it easily converts to on-board applications using the TDAS G5 Vehicle Docking Station or the TDAS G5 iPort for smart load cell walls and crash barriers.


Technical Specifications:  Click Here


TDAS PRO

SLICE PRO LAB

TDAS PRO


TDAS PRO is the original, rugged modular data acquisition system designed by DTS. Customers worldwide continue to rely on TDAS PRO systems daily for critical testing. DTS continues to service and support all TDAS PRO equipment worldwide.




Technical Specifications:  Click Here



DATA LOGGERS

TSR PRO / TSR PRO-HB

TSR PRO / TSR PRO-HB

TSR PRO / TSR PRO-HB


Compact and rugged, TSR PRO and TSR PRO-HB data loggers make it easy to measure acceleration forces in dynamic test environments. Simple and reliable, the TSR PRO and TSR PRO-HB store up to 2000 events in flash memory and are ideal for both short duration tests and long-term monitoring.



Technical Specifications:  Click Here


Return to Top

TSR 3DXC / TSR 6DXC

TSR PRO / TSR PRO-HB

TSR PRO / TSR PRO-HB


Ultra high-shock rated, high sampling data loggers with internal triaxial accelerometer and angular rate sensors fielded by the U.S. Army as vehicle blast event recorders. The TSR 3DXC and TSR 6DXC write data to flash memory and offer a CAN Bus or USB interface option.


Technical Specifications:  Click Here

TSR 3DXP / TSR 6DXP

TSR PRO / TSR PRO-HB

TSR 3DXP / TSR 6DXP


Compact and ultra high-shock rated, the TSR 3DXP and TSR 6DXP data loggers feature built-in triaxial accelerometers, angular rate sensors and a pressure sensor. Ideal for blast and high energy environments, the TSR 3DXP and TSR 6DXP write data directly to flash memory.


Technical Specifications:  Click Here


Sensors

ARS PRO & ARS HG

ARS PRO & ARS HG

ARS PRO & ARS HG


World’s smallest, ultra-high shock tolerant uniaxis angular rate sensors. The ARS PRO and ARS HG are designed to measure high rates of angular velocity in dynamic testing environments.


Technical Specifications:  Click Here


Return to Top

ARS3 PRO

ARS PRO & ARS HG

ARS PRO & ARS HG


Ultra-small, high shock tolerant angular triaxial rate sensor package. The lightweight ARS3 PRO is designed to measure high rates of angular velocity in dynamic testing environments.


Technical Specifications:  Click Here

6DX PRO

ARS PRO & ARS HG

6DX PRO


World’s smallest, high shock tolerant six degrees of freedom sensor package. The low mass 6DX PRO includes three angular rate sensors, plus three accelerometers in a rugged enclosure designed for dynamic testing.


Technical Specifications:  Click Here

IB-6

Thermocouple Adaptor

6DX PRO


Ideal for lower-rate measurements, the Texense IB-6 is a six degrees of freedom sensor package with three angular rate gyroscope sensors, plus three accelerometers. The ultra-small IB-6 inertial sensor is a high performance 6-axes inertial box, used by the world’s leading WRC, F1 and WEC motorsports teams.


Technical Specifications:  Click Here


Return to Top

6DX G2

Thermocouple Adaptor

Thermocouple Adaptor


The ultra-small 6DX G2 six degrees of freedom sensor direct-mounts to SLICE6 DAQ for a cable-free solution. The low mass 6DX G2 includes three angular rate sensors, plus three accelerometers in a rugged enclosure. Designed for the U.S. Army WIAman blast ATD.



Technical Specifications:  Click Here

Thermocouple Adaptor

Thermocouple Adaptor

Thermocouple Adaptor


The plug-n-play THA Thermocouple Adaptor by Texense makes it easy to integrate temperature data with other acquired signals using SLICE data acquisition systems. The rugged and compact adaptor supports Type K Thermocouples using SLICE NANO, SLICE MICRO, SLICE IP68 and SLICE PRO data acquisition systems.


Technical Specifications:  Click Here

ATD SOLUTIONS / ATD DUMMIES

IN-DUMMY DAS

WorldSID IN-DUMMY DAS

THOR IN-DUMMY DAS


DTS offers a variety of das in-dummy solutions for the complete family of anthropomorphic test devices (ATDs) and pedestrian safey testing. Embedding the das in dummy improves data quality, reduces set-up time and eliminates trailing cables that can tangle or alter test dynamics. Innovative DTS das dummy solutions are leading the way for automotive safety, injury biomechanics, aerospace and military blast testing to measure skeletal injuries.


Technical Specifications:  Click Here


Return to Top

THOR IN-DUMMY DAS

WorldSID IN-DUMMY DAS

THOR IN-DUMMY DAS


 The SLICE6 THOR dummy is the most advanced ATD for Euro NCAP automotive safety testing. To support the high-channel test requirements, THOR is integrated with SLICE6 dummy das. Embedding the data acquisition and sensors in dummy reduces set-up time, improves data quality, and eliminates heavy trailing cables that may alter dummy positioning or test dynamics.




Technical Specifications:  Click Here

WorldSID IN-DUMMY DAS

WorldSID IN-DUMMY DAS

Hybrid III IN-DUMMY DAS


The WorldSID dummy is the first regulation anthropomorphic test device (ATD) for automotive safety testing designed with DTS dummy DAS. Embedding the data acquisition and sensors inside the WorldSID dummy reduces test set-up time, improves data fidelity and eliminates the large trailing umbilical cable that can make dummy positioning challenging and alter test dynamics.




Technical Specifications:  Click Here

Hybrid III IN-DUMMY DAS

Hybrid III IN-DUMMY DAS

Hybrid III IN-DUMMY DAS


DTS offers multiple dummy das solutions for the frontal impact Hybrid iii dummy. DTS integrated in-dummy DAS are complete turn-key solutions designed to maintain proper mass and CG. Embedding the Hybrid dummy DAQ eliminates the heavy trailing umbilical cables, significantly reduces test set-up time, plus improves repeatability and data quality. DTS offers Hybrid in dummy kits and in-house integration services, plus expert worldwide technical support.



Technical Specifications:  Click Here


Return to Top

WIAMan BLAST MANIKIN

Hybrid III IN-DUMMY DAS

WIAMan BLAST MANIKIN


The U.S. Army WIAMan dummy (Warrior Injury Assessment Manikin) is the first ATD with embedded SLICE6 dummy DAS to measure vertical loads. The WIAMan dummy is a biofidelic, warfighter representative engineered to assess potential skeletal injuries of soldiers exposed to underbody blasts (UBB). WIAMan supports up to 156 channels of SLICE6 dummy DAS.





 Technical Specifications:  Click Here

SLICE aPLI LEGFORM

Hybrid III IN-DUMMY DAS

WIAMan BLAST MANIKIN


Integrated SLICE NANO and sensors in the new advanced Pedestrian Legform Impactor (aPLI) help improve safety and survivability of pedestrians involved in accidents worldwide. The standard configuration for the new aPLI includes 18 channels of SLICE NANO DAQ and a 6DX PRO sensor (triaxial angular rate and triaxial accelerometer) in the upper-body mass, along with a single-axis ARS PRO angular rate sensor in the knee.




Technical Specifications:  Click Here

SLICE FLEX PLI LEGFORM

SLICE FREE MOTION HEADFORM

SLICE PEDESTRIAN HEADFORM


The SLICE Flexible Pedestrian Legform Impactor (FLEX PLI) integrates the ultra-small SLICE NANO data acquisition system into a cable-free pedestrian safety testing solution. Offering the ultimate in flexibility, reliability and repeatability, the SLICE FLEX PLI Legform eliminates all trailing cables. A quick-charging super capacitor ensures reliable data capture and storage. Data writes directly to flash memory.


Technical Specifications:  Click Here


Return to Top

SLICE PEDESTRIAN HEADFORM

SLICE FREE MOTION HEADFORM

SLICE PEDESTRIAN HEADFORM


The SLICE Pedestrian Headform Impactor integrates the ultra-small SLICE NANO data acquisition system and sensors for a cable-free pedestrian safety testing solution. SLICE offers the ultimate in flexibility, reliability and repeatability by eliminating all trailing cables. The SLICE Pedestrian Headform writes data to flash memory.




Technical Specifications:  Click Here

SLICE FREE MOTION HEADFORM

SLICE FREE MOTION HEADFORM

SLICE FREE MOTION HEADFORM


The SLICE Free Motion Headform (FMH) integrates the ultra-small SLICE NANO data acquisition system into a cable-free automotive safety testing solution. Offering the ultimate in flexibility, reliability and repeatability, the SLICE Free Motion Headform is a turn-key solution that directly writes data to flash memory.





Technical Specifications:  Click Here

DTS Software

DataPRO

SLICEWare

SLICEWare


DataPRO is a powerful set-up, control and data viewing software including ISO MME support. The modern user interface is designed to help test engineers create, control and manage every aspect of a test. DataPRO can be installed with an SQL server database and configured with individual user logins and access levels to support facilities and users of all sizes and capabilities. DataPRO works with all SLICE, TDAS G5 and TDAS PRO hardware and is required for systems using SLICE PRO TOM, DIM or TDM modules



Technical Specifications:  Click Here


Return to Top

SLICEWare

SLICEWare

SLICEWare


SLICEWare is an intuitive set-up, control and data viewing software for SLICE6, SLICE NANO, SLICE MICRO, SLICE IP68 and SLICE PRO SIM hardware. Designed to provide fast, easy-to-use tools for data collection, SLICEWare is ideal for both small and large-scale tests. SLICEWare offers advanced features such as automatic sensor assignment, detailed channel diagnostics and real-time data display to support successful data collection every test.



Technical Specifications:  Click Here


TSR Control

TDAS Control

TDAS Control


TSR Control is the user-friendly set-up, control and viewing software for the entire line of TSR data loggers. An intuitive interface makes it easy to configure the recorder, view real-time sensor output and review time-history data. Via a PC, users can set the record time (seconds), trigger threshold (g) per axis, and download individual or multiple events stored in flash memory. TSR Control also includes tools for zoom, filtering and Head Injury Criteria (HIC) calculations


Technical Specifications:  Click Here


 Return to Top

TDAS Control

TDAS Control

TDAS Control


TDAS Control is the original set-up, control, viewing and export software developed by DTS. TDAS Control provides easy-to-use tools for configuring output timing, as well as advanced features such as automatic sensor assignment, detailed channel diagnostics, real-time display and squib fire for airbag testing. TDAS Control only works with TDAS G5 and TDAS PRO.




Technical Specifications:  Click Here
