CRFS INC

Detect and locate signals of interest.  Knowing that a transmission exists is important, but knowing the location of that transmission can deliver vital intelligence in both military and civilian applications.

  -  UAS (drone) detection

  -  Locating RF interference sources

  -  Border security

  -  Aircraft tracking

  -  Geolocating the enemy by their transmissions

CRFS solutions are able to detect, classify and locate signals of interest over a wide area

Return to Top

CRFS provides intelligent systems for real-time monitoring and management of the RF spectrum. Their systems (RFeye Nodes and RFeye Arrays) can be deployed indoors or outdoors to autonomously and continuously monitor spectrum, sending data in real time over IP to a remote operator. The intelligence of the RFeye spectrum monitoring systems allows tasks to be scheduled and key insights to be highlighted, removing the need for operators to observe spectrum 24/7.

The quest for illicit intelligence is a never-ending threat; from criminals trying to obtain information for financial gain, to sophisticated state-sponsored adversaries looking for political and military gains. While we do not always know what kind of threats are around us, a robust security policy encompassing physical security, cyber security and protection from electronic surveillance is needed to ensure secrets remain secret. The security of your building, your Sensitive Compartmented Information Facility (SCIF), your private conversations, your plans and secrets can all be compromised by small, inexpensive surveillance devices (GSM bugging devices are available today from well-known online retailers for less than $50).

Critical National Infrastructure (CNI), typically defined as assets essential to the safety, security and economic well being of a country, require the highest levels of protection to prevent, mitigate and enable effective response to risks. Those charged with Critical Infrastructure Protection (CIP) face a heavy responsibility to ensure the risk of disasters (including loss of life and severe economic damage) are minimized as far as possible. Governments also impose strict regulations surrounding the protection of national infrastructure, meaning that even where there are no consequences to an unmanaged risk, organizations can still face financial penalties for failing to address it.

Return to Top

Drones and UAS (Unmanned Aircraft Systems) have many positive and legitimate uses but there are increasing concerns that drones are being used for illegal and dangerous activities: flying too close to passenger aircraft, smuggling drugs/weapons into prisons, privacy concerns and even weaponized drones. The list grows daily, as do the incidents.  RFeye Drone Defense is a passive RF sensing system that geolocates drone & operator emissions in 3 dimensions: latitude, longitude and altitude. The system can track multiple drones simultaneously and alert operational/security staff to the confirmed presence of a drone and its location, all in real time.

 RFeye AirDefense is a wide-area 3D geolocation and intelligence system that can identify and track aircraft while remaining invisible to electronic detection. Its covert nature makes the system ideal for border monitoring, radar augmentation, target acquisition, spoofing detection and more. RFeye AirDefense solution uses 3D TDOA to achieve highly accurate tracking of RF emissions from objects such as enemy aircraft without emitting any electromagnetic signature that may give away your presence.

The RFeye Node 100-18 offers the capabilities of the Node 50-8 but with extended instantaneous bandwidth of 100 MHz and a frequency range up to 18 GHz. Like the other RFeye Nodes in the family, it is a complete spectrum monitoring and geolocation system designed for remote deployment in distributed networks both indoors and outdoors, including in hostile environments. Packaged in a compact, rugged and a weatherproof housing, it has been optimized for size, weight and power (SWaP) and is simple to connect to power and network.

The RFeye Node 100-8 uses the latest superheterodyne receiver technology to provide outstanding quality and performance at a highly competitive price. It is a complete spectrum monitoring and geolocation system designed for remote deployment in distributed networks both indoors and outdoors, including in hostile environments. Packaged in a compact, rugged, weatherproof housing, it has been optimized for size, weight and power (SWaP) and is simple to connect to power and network.

The Node 50-8 is characterized by outstanding phase noise, noise figure, channel retune time and spurious free dynamic

range parameters, well above any other product in its class.  It also offers all of the multi-mission capability of the RFeye

product range allowing multiple concurrent measurements and geolocations to be performed and multiple users to connect

simultaneously from remote locations. The Node 50-8 includes an on-board SSD for logging large data sets.

The RFeye Array 100 family is designed for vehicle-mounted, transportable or ground-fixed installations. It is a fully integrated plug-and-play system containing a high-performance RFeye Node, spiral antenna modules and high-speed switch and is available with optional IP65 radome and mounting kit. The RFeye receiver commutates at very high speed around the antennas to make near-simultaneous AOA measurements in multiple directions.

Return to Top

The Array 300 is an intermediate-sized system for vehicle-mounted deployment or fixed installations. It is available in two different receiver configurations based on the class-leading RFeye Node 100-8 with 100 MHz IBW and 8 GHz upper frequency, or Node 100-18 with 100 MHz IBW and 18 GHz upper frequency.

The Array 300 uses a unique multi-layer approach that is more sophisticated and versatile than traditional direction finding. High-performance spiral directional antenna modules are optimized for different frequency bands and arranged in multiple orientations. The Array is sensitive to the majority of incoming signal polarizations including all linear polarizations, allowing reliable detection of signals including those invisible to most DF systems.

The Array 500 is the “big brother” of the Array 300 and is for fixed installations. It contains larger spiral antennas on the lower tier, allowing accurate AOA measurements down to 100 MHz. It is available in two different receiver configurations based on the class-leading RFeye Node 100-8 with 100 MHz IBW and 8 GHz upper frequency, or Node 100-18 with 100 MHz IBW and 18 GHz upper frequency. The Array 500 uses a unique multi-layer approach that is more sophisticated and versatile than traditional direction finding. High-performance spiral directional antenna modules are optimized for different frequency bands and arranged in multiple orientations.

Feye Guard is a continuous TSCM (Technical Surveillance Countermeasures) solution that combines highly sensitive and broad bandwidth receivers with simple autonomous software to ensure you never miss an illicit signal.

The high-specification receiver technology is able to detect low-power and advanced signals that would be missed by many handheld sweepers. And since electronic surveillance devices are not guaranteed to operate in obvious parts of the RF spectrum, the ability to continuously monitor the spectrum up to 18 GHz is a critical feature built into our systems. Sweep rates of almost 400 GHz/s and a resolution down to 1 Hz enable the highest possible probability of interception to be achieved.

Return to Top

The Indoor Ceiling Mounting Kit from CRFS comes pre-assembled and ready for installation into a suitable suspended ceiling. The omni antenna, RFeye Node and SyncLinc module are all contained in an unobtrusive housing to fit into any office environment.

The ceiling kit has been designed to work with the RFeye Guard solution, to enable continuous TSCM monitoring in secure or sensitive buildings.

The Outdoor System Kit from CRFS enables your RFeye Node to operate in some of the harshest conditions. It comes pre-assembled and ready for wall, pole or mast mounting, providing a maintenance-free, 24/7 spectrum monitoring solution.

Note that outdoor kits for our RFeye Guard system are specially designed for this application and therefore may have slightly different specifications.

The RFeye Stormcase is a man-portable integrated system designed for easy mobile spectrum monitoring from a fully autonomous and ruggedized stand alone unit. Built into a tough storm case, the system includes a Node 100-8 or a 100-18, internal and external antenna ports, high performance rechargeable battery and integrated SSD memory for high volume data collection during mobile field operations.

Return to Top

SyncLinc permits time synchronization of multiple RFeye Nodes. The goal is to allow each node to capture data within one sampling clock cycle of another, by distributing an accurate timing reference from a master sensor to a group of slave sensors.

This highly accurate common-timing reference allows advanced correlative operations, including high-accuracy Power On Arrival (POA) geolocation with indoor Nodes, retaining the full performance of the RFeye Node, even for transient and low-power signals.

CRFS provides a range of solutions for vehicle-based monitoring and direction finding including custom integrated surveillance vehicles such as Toyota Land Cruisers and Mercedes Sprinter vans built to customer specifications.

We work with a number of experienced partners to install all required measurement instruments onto the vehicles and to carry out any required vehicle modifications to accommodate comfortable long duration missions.

RFeye Mission is CRFS’s flagship solution for automated spectrum operations. It enables spectrum stakeholders to derive useful and actionable intelligence from their deployed RFeye receivers without the need for teams of RF experts. It has been designed for use with RFeye assets deployed over wide areas such as ranges, test sites, borders and cities and also for small networks such as in-building TSCM monitoring.

RFeye Mission is controlled via a web browser interface. It enables the automated scheduling of spectrum monitoring tasks to be performed without the need for the user to view a “wall of spectrum data.” Sweeps, scans and surveys can be quickly set up, and authorized transmitters, operating zones and geolocations are clearly displayed as well as incidents and alarms as they happen.

RFeye® Site is our state-of-the-art desktop application for all your real-time monitoring and geolocation requirements. It includes all the essential functionality needed for spectrum monitoring and management tasks such as: carrying out RF spectrum sweeps; IQ capture; measurements of power, occupancy, bandwidth and frequency deviation; and visualization via interactive charts and graphs. However, RFeye Site goes far beyond this with a vast array of advanced functionalities combined in one software suite which is ideal for the RF expert

RFeye DeepView software is the ultimate signal extraction tool. Its robust indexing feature allows users to sift through multi-terabyte datasets and quickly find and export signals of interest (SOIs). DeepView extracts SOIs in as small a file as possible, slicing file snippets using both time and frequency limiters to facilitate rapid file transport and smarter data management.

Designed for use with the SenS range of I/Q recorders, DeepView captures hours or days of full-rate, 16-bit I/Q data in real time, up to 100 MHz per receiver channel. The low noise figure and phase noise of the SenS recorders provides unparalleled signal fidelity, enabling users to find and analyze mission-critical signals, including narrow- or wideband, low-power, short-pulsed, co-channel or even frequency-hopping signals.
